Measurement and Quality Control (P- 122):
Major Equipment:
| Sr.No. | Equipment Name | Specifications | Qty. |
|---|---|---|---|
| 1 | ROTAMETER FLOW MEASURING UNIT | Flow range- 0 to 1000 lph Scale- 0 to 35 cm |
01 |
| 2 | TEMPERATURE CALIBRATION SETUP | Temp. range – 0 to 1000 C Thermocouple- J, K type |
01 |
| 3 | STROBOSCOPE | Range 0 to 3600 rpm | 01 |
| 4 | ADVANCED TOOL MAKERS MICROSCOPE | Optical head- Monocular Range- 50mmX50mmX70mm Objective lenses – 2X |
01 |
| 5 | PROFILE PROJECTOR | X,Y resolution – 0.0005 Sway range- +- 150 |
01 |
Other Equipment:
| Sr.No. | Equipment Name | Qty. |
|---|---|---|
| 01 | LVDT | 01 |
| 02 | FLOATING CARRIAGE DIAMETER MEASURING MACHINE | 01 |
| 03 | AUTOCOLLIMATOR & ANGLE DEKKOR | 01 |
